Round Wood Milling Machine Wood Working Round Rod milling Wood Stick Making Machine

Model

MC9020

MC9050A/B/C

MC9060A/B/C

MC9080B/C

Type

A  Single in and single out  B double in and single out  C Double in and double out , for new user we recommend C type

Main motor power (kw)

2.2

3

3

4

Feeding motor power(kw)

0.55

0.75

0.75

0.75

Worm wheel decelerator

50:1  60 type

Processing diameter

6~20mm

15~50mm

15~60mm

20~80mm

Feeding speed

3~5m/min double pully gear

Spindle speed

5000r/min

4000r/min

Shortest processing length

300mm

400mm/500mm/600mm

Largest chipping allowance diameter

2mm

4mm

Dimension(mm)

760*560*820, (860/970/1100)*650*980,

Weight(kg)

170

250/310/350/420

Noted:

We also provide Max. Processing diameter: 100mm,120mm, 150mm and 200mm
