MZX-506/MZX-5114 6 /14 drilling and milling shafts tenon and mortise machine for Crib, Multi Boring Slot Mortiser
- Quantity
MZX-506/MZX-5114 6 /14 drilling and milling shafts tenon and mortise machine for Crib
|
Model |
MZX-506 |
MZX-5114 |
|
Drilling and milling shaft number |
6 |
14 |
|
Max. Drilling depth |
65mm |
100mm |
|
Max. Drilling length |
100mm |
100mm |
|
Working table size |
1260*360mm |
2200*360mm |
|
Milling slot width |
3~16mm |
4~20mm |
|
Min. Drilling center distance |
50mm |
50mm |
|
Spindle speed |
6000r/min |
9000r/min |
|
Spindle motor |
2.2/3kw |
8kw(4kw*2) |
|
Stocke motor power |
0.37kw |
0.75kw |
|
Weight |
600kg |
900kg |
MZX-506/MZX-5114 6 /14 drilling and milling shafts tenon and mortise machine for Crib
Horizontal multi-axis drilling and milling machine is a more commonly used equipment for the production of bamboo products and solid wood furniture. The wood machine is equipped with six drilling and milling shafts (can be increased or decreased) to drill six slots at a time. The slot hole has high smooth precision, and the center distance of the drill seat can be adjusted to 50 mm, good choice for Crib,Wooden bed, dining table and chairs, cabinets, handicraft processing.
