JP6/JP8/JP801 Electric Surface Flat Wood Jointer Planer Machine The Portable Planer For Woodworking
- Quantity
|
Type |
JP6 |
JP8 |
JP801 |
|
Working table size |
1215×184mm |
1550×230mm |
1800×230mm |
|
Spindle speed |
4400rpm/50HZ |
4400rpm/50HZ |
4800rpm/50HZ |
|
Blade number |
3PCS |
3PCS |
4PCS |
|
Blade shaft diameter |
ø61mm |
ø65mm |
ø75mm |
|
Max. Planing depth |
3mm |
3mm |
3mm |
|
cast iron planer(G.W./N.W.) |
85kg /76kg |
121kg ／105kg |
155kg ／141kg |
|
Cover weight G.W./N.W.) ） |
37kg /36kg |
38kg/37kg |
42kg/40kg |
|
Dimension(mm) |
L1240×W370×H300 |
L1860×W440×H300 |
L1860×W440×H300 |
|
|
L420×W400×H650 |
L560×W440×H650 |
L560×W440×H650 |
Tailor-made for woodworking masters, saving time and effort.
It is suitable for planing all kinds of wooden boards and artificial boards.
The wood chips are stored and discharged, and the working environment is clean and hygienic.
Simple operation, easy to use,
Metal base with smooth planed surface
