| Performance |
Max splitting power |
20T |
| Max splitting length |
Standard 610mm (24 inch) |
| Max cutting & splitting diameter |
480mm (19 inch) |
| Cycle time |
8-12S |
| Work efficiency |
4-7CBM/H |
| Wood fixing |
Hydraulic |
| Saw cutting |
Joystick with solenoid valve |
| Saw lubrication |
Automatic by hydraulic system |
| Splitting |
Automatic |
| Splitting wedge |
4 way (height adjustable) |
| Machine assembly |
Engine |
7.5KW hydraulic motor |
| Pump |
20GMP (2-stage) |
| Splitting cylinder |
3.15”x24”x2” |
| Hydraulic oil tank |
100L |
| Feeding conveyor |
2400*200mm |
| Rear loading conveyor |
3200*250mm |
| Tyre |
22x11-10 |
| Traction |
50mm ball couple |
| Packing |
Size |
2300x1250x1750mm |
| Weight |
980KG |
| Loading Q\ty |
7/16 pcs (20GP/40HQ) |
