Double Sided Woodworking Thicknesser MB202D MB203D MB204D | Updated Version of MB202C MB203C MB204C Wood Planer Machine
Chat with us on Whatapp for instant quotes& support
Full series double-sided wood planer MB202D/MB203D/MB204D, upgraded models of MB202C/MB203C/MB204C. Heavy-duty steel structure, low noise, double feeding speed, high precision. 200mm/300mm/400mm working width optional, ideal for small & medium woodworking workshops worldwide.
Technical parameter
Model: MB202D/MB203D/MB204D ( Updated MB202C/MB203C/MB204C)
Spindle speed: 7800r/min
Feeding speed: 7m/min, 9m/min
Max. planing width: 200/300mm
Max. planing thickness: 200 mm
Min. planing thickness: 8mm
Min. planing length: ≥260mm
Upper cutter max. cutting depth: 4mm
Lower cutter max. cutting depth: 2mm
Motor power: 3kW /4KW/ 5.5KW/7.5KW 380V
Overall dimensions: 880×(600/700/800)×1200mm
✅ Core Advantages
Heavy steel body with professional heat treatment, stable running & low noise
7m/min & 9m/min dual feeding speed, flexible for different wood processing
High-speed spindle with strict dynamic balance, smooth planing surface
Adjustable cutting depth, easy operation & low maintenance cost
Compact size, easy shipment, perfect for SOHO export & small workshop use
